AECM104FBSi

Auto start modules

Model: AECM104FBSi

AECM104FBSi Description

The Model AECM104FBSi is a microprocessor operated Automatic Engine Control Module designed to automatically and manually start and stop the engine. It will indicate the operational status and fault conditions, automatically shut down the engine and indicate the start engine failure by a flashing "Start Fail" LED on the front panel. Other simultaneous faults are indicated by steady LED. Read more...

Key Features

  • Remote / Manual start and stop

  • Low oil pressure shut down

  • High engine temperature shut down

  • Manual / Remote shutdown by pressing emergency stop push button

  • Over speed shut down

  • Under speed shut down

  • Self-regulated duration of each attempt

  • All outputs are protected from overload by resettable multi fuse

  • Automatic pre-heat before start via glow plug (optional, please consider using table "A" shown below)

  • Automatic load control (optional, please consider using table "A" shown below)

  • Can be programmed to work with normally open fuel solenoid (energize-to-stop type)

  • Wireless start / stop (optional, please consider using table "A" shown below)

  • Very low power consumption in stand-by mode (10mA max)

  • All parameters are user configurable (prior to order)

Table A

Optional Features/Items

Item

Price

GBP

Output for a glow plug (pre-heat)

12.00

Load Control output

12.00

Battery Voltage Sensor (BVS)

29.00

N/O fuel solenoid valve settings

(energise-to-stop)
(with mechanically driven fuel pump)

42.00

N/O fuel solenoid valve settings

(energise-to-stop)
(with electrically driven fuel pump)

56.00

Wall mountable 24/7 Digital timeswitch

24.00

Wireless start / stop
remote control (key fob)
(no battery fitted)

22.00

DC alternator excitation output (WL terminal on DC alternator)

5.00

Emergency stop button

10.00

12V 1A Lead acid trickle charger

10.00

40A 12V or 24V fuel/starter/pre-heat/
load/ control
external power relays.

From 3.00 (each)
